Tile Sizes
• 1200 x 600mm
• 600 x 600mm
• 1200 x 300mm
• 1200 x 400mm
• 1500 x 300mm
* Bespoke sizes available upon request.

Tile Types
Choose from 9 individual tile types, based on your acoustic & performance needs.
.jpeg)
SUMMIT
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Fleece Face
Pattern: Non Directional Design
Recycled %: 72% Recycled Content
Performance:
15mm = NRC 0.65 / CAC 35
19mm = NRC 0.70 / CAC 40
.jpeg)
SUMMIT NRC+
Material: Mineral Fibre
Colour: White & Black
Thickness: 19mm
Surface: Fleece Face
Pattern: Non Directional Design
Recycled %: 60% Recycled Content
Performance:
19mm = NRC 0.85 / CAC 35

STELLAR
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Latex Paint with Non-uniform Perforated Face
Pattern: Non Directional Design
Recycled %: 45% Recycled Content
Performance:
15mm = NRC 0.60 / CAC 35
19mm = NRC 0.70 / CAC 40

SIROCCO
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Sand Textured Face
Pattern: Non Directional Design
Recycled %: 60% Recycled Content
Performance:
15mm = NRC 0.50 / CAC 35
19mm = NRC 0.55 / CAC 40

SIROCCO PINHOLE
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Perforated, Sand
Textured Face
Pattern: Non Directional Design
Recycled %: 60% Recycled Content
Performance:
15mm = NRC 0.55 / CAC 35
19mm = NRC 0.65 / CAC 40

ASTRID
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Latex Paint with
Perforated Face
Pattern: Non Directional Design
Recycled %: 45% Recycled Content
Performance:
15mm = NRC 0.60 / CAC 35
19mm = NRC 0.70 / CAC 40

CLEANSHIELD
Material: Mineral Fibre
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Polyester Fibre Coating
Pattern: Non Directional Design
Recycled %: 60% Recycled Content
Performance:
15mm = NRC 0.65 / CAC 35
19mm = NRC 0.90 / CAC 40

MEDISHIELD
Material: Mineral Fibre Laminated with Transparent Acoustic Tissue
Colour: White & Black
Thickness: 15mm & 19mm
Surface: Advanced Antibacterial Properties
Pattern: Non Directional Pattern Design
Recycled %: 72% Recycled Content
Performance:
15mm = NRC 0.65 / CAC 35
19mm = NRC 0.70 / CAC 40

ELEGANT
Material: Fibreglass
Colour: White & Black
Thickness: 20mm
Surface: Fleece Face
Pattern: Non Directional Design
Recycled %: 75% Recycled Content
Performance:
20mm = NRC 0.95 / CAC 26
Tile Edge Details
Choose from 5 different tile edge details, based on your selected grid type and product application.





Top Hat Grid
with c-spline edge
Ref: CS
Top Hat Grid
with square edge
Ref: SQ
T-Bar Grid
with square edge
Ref: SQ
15mm T-Bar Grid
with tegular edge
Ref: TG15
24mm T-Bar Grid
with tegular edge
Ref: TG24
Note: Edge details & grid options are not suitable for all environments. Please consultant your MBS Architectural representative to confirm the best ceiling grid for your application.
Grid Types & Perimeter Trims
The suspension systems are either a two way exposed 24mm T-Bar Grid, and a two way exposed 32mm Top Hat Grid, specifically designed for plank tiles.
Note: For seismic details – contact MBS.

24mm T-Bar Grid

32mm Top Hat Grid


Wall Angle
Shadow Line Wall Angle
